NSK Bearing Strengthen Sheet Feed Paper Roll Bag Making Machine For Starch Bags

Name: NSK Bearing Strengthen Sheet Feed Paper Roll Bag Making Machine For Starch Bags
Brand: Tecon
Price: 1 USD

Brand Name : Tecon

Model Number : HD4916B

Certification : CE

Place of Origin : China

MOQ : 1pcs

Price : negotiation

Payment Terms : T/T or L/C

Supply Ability : 16pcs per year

Delivery Time : 3-5 months after received your payment

Packaging Details : Ply Wood case

Speed : MAX 80 bags/min

Bag length : 390～1020 mm

Bag width : 80～160 mm

Bottom Center Distance : 290～860 mm

Tube length : 670~1035 mm

Tube width : 420~600 mm

Strength sheet length *width : Strength sheet length *width

Contact Now

NSK Bearing Strengthen Sheet Paper Bag Forming Machine For Starch

HD4916B Bottomer Machine Operating condition

Speed	MAX 80 bags/min
Tube Width	380～620 mm
Bottom Width	80～160 mm
Valve Sheet Length *Width	(100-300)﹡(120-340)adjustable
Number of ply	2~4paper+1 PP/PE
Strength sheet unit	YES
Main Drive Motor	35KW
Machine size	23.5﹡2.3﹡1.8(M)
Machine weight	N34(T)

Features of our full-automatic paper bag production line:

1. High Speed Rotary Feeder
2. Tube Alignment
3. Deflector for Irregular Tubes
4. Bottom Creasing Line Station
5. Air Vent Perforation
6. Bottom Opening Unit
7. Valve Station with Winding Station
8. Pasting Internal Strengthen Sheet Unit
9. Bottom Closing Stations
10. Pasting External Strengthen Sheet Unit

Our machine:

Automatic valve paper bag machine for cement,chemicals and food

NSK Bearing Strengthen Sheet Feed Paper Roll Bag Making Machine For Starch Bags

The ZT9802S tuber machine, which is developed by our company on the basis of ZT9804 standard tuber

machine, is added a servo control component on each of the four key procsses (printing,perforation,

gluing and separation), to form a closed-loop servo control system by the PLC, servo control module,

the main frequency traction motor, servo motor group,encoder, color components to ensure that the

cutting position of each printing bags matches the color patch of the tube.

Welcom to contact us or visit our .we are ready here.
